Commercial Reverse Osmosis 6000 GPD | 22,750 LPD
Brand: Ampac USA
Product Code: APRO6000
Made in USA
The AMPAC USA Commercial Reverse Osmosis 6000 GPD / 22,750LPD|APRO6000 is the result of 28 years of experience with the needs and requirements of commercial pure water users. The key factors are reliability, serviceability, and consistent performance with minimum user intervention are achieved in the solid design of the AMPAC USA Reverse Osmosis Systems.
Standard Features:
- Spin Down Screen Filter with Manual Flush Valve
- Silica quartz Pre-Filter w/auto-backwash valve
- 4” x 20” Big Blue Sediment Pre-Filter 20 Micron
- 4” x 20” Big Blue Sediment Pre-Filter 05 Micron
- Multi-Stage High-Pressure Jet Pump with Safeguards for Brackish Water Application
- Four Count 4” x 40” FRP Pressure Vessels (Stainless Steel or FRP)
- Four Count 4” x 40” TFC Membrane Element
- Complete Panel for Easy Controls
- 4 Count Stainless steel liquid-filled pressure gauges
- Permeate and concentrate flowmeters
- Inlet Solenoid Valve with Bypass
- Low pressure cut off Pressure Switch
- Stainless Steel System Pressure Control
- Stainless Steel Recycle Pressure Valve
- On/Off Main Power Switch
- Powder-coated, Welded Aluminum Frame with Aluminum Diamond Plate.
Optional Features:
- Automatic Operating Programmable logic controller UL/CE Approved with:
- Smart Relay
- Delayed start-up of the high-pressure pump
- Inlet Solenoid Valve
- Low & High Feed Pressure Switch Controls
- Supply & Delivery Pumps Controls
- R/P Storage Tank Full Pump on/off
- Auto Flush Cycle
- Pre-Treat Lockout
- TDS/Conductivity Monitor
- Temperature Monitor
- Hour Meter
- Ion Exchange Water Softener w/auto-backwash valve
- Multimedia KDF-Catalytic Carbon-Poly Phosphate Pre-Filter w/auto-backwash valve
- Anti-Scalant Dosing System (Hard Water Present Conditions)
- Chlorine Dosing System (Iron Manganese Present Conditions)
- Smart-on-Demand Delivery (Distribution) Pump to Point of Use 2HP.
- 4” x 10” Big Blue Carbon Post-Filter 05 Micron
- Ultra Violet Sterilizer
- Smart-on-Demand Supply Pump to increase Feed Water Pressure 1HP
- Ozone Generator Disinfection System Installed on Circulation Loop.
System Features:
Frame | Powder Coated One Piece Aluminum w/Diamond Plate |
Membranes | (4) ea TFC 4" x 40" |
Vessels | 4" x 40" Stainless Steel or FRP |
Pump | Goulds Multi Stage Jet Pump with Safeguards (SS option) |
Gauges - Glycerin | Pre-Filter PSI, Post-Filter PSI, Booster Pump PSI |
Valves | System Pressure, Recycle Pressure |
Switches | Low PSI Cutout, Tank Full Cutout |
Electrical | 110 or 220 V, 50 or 60 Hz, 1 phase or 3 phase |
Motor | 2 Hp - 1725 rpm |
Connections | 1" Quick Tubing Connectors |
Capacity per Gallon | 4.2 gal per min - 6,000 gals per day |
Capacity per Liters | 15.8 Liters per min - 22,750 Liters per day |
Operating Pressure | 170 - 225 psi |
Typical Recovery | 33% - 75% |
Typical Rejection | 99% |
Max Feed TDS | 2500 ppm - 15 grains For Municipal Water Design |
Max Feed TDS - | 10,000 ppm - 25 grains For Brackish Water Design |
Max Feed Temp | 113 degrees F |
Feed pH Range | 2-11 |
Max Chlorine | less than 0.1 ppm |
Dimensions | 22" wide x 22" deep x 57" ht. |
Weight | 180 Lbs. / 82 Kgs. |
Make of System: Fully Automated Turnkey Water Purification System including pre-treatment Modules and Reverse Osmosis System fully built on a Powder Coated Welded Aluminum Skid with Diamond Plate Base using good industrial practice and following manufacturer’s guidelines for every component.
Make of System: AP6000
Origin: Made in USA
Backwash & Regenerations Cycle: Ion Exchange System Cycle on Metered Basis, Multimedia System Cycle on Timer Basis and can be Adjustable up to 120 Minutes at any given time.
Delivery Terms: System is ready to be crated and shipped, on average 2-3 Weeks from the day of receipt of purchase order.
System production is based on the following conditions: 10,000ppm NaCI feed water, 77°f/ 25°c Operating temperature and 3.0-11.0pH Range. Actual feed water analysis may require special consideration affecting final design and pricing.
