Industrial Reverse Osmosis 6,000 GPD | 22.7m3/Day

The AMPAC USA AP6000-SM-LX Industrial Reverse Osmosis 6,000 GPD is a Fully Automated, Fully Equipped Superior Quality Drinking Water Purification Reverse Osmosis System, built on an aluminum fully welded skid with an aluminum diamond plate, specifically designed for Water Store Applications.

The AMPAC USA AP6000-SM-LX Reverse Osmosis Water Purification System contain everything needed to purify and deliver the purified drinking water to the filling or bottling sources,

The AMPAC USA AP6000-SM-LX is capable of producing 6000 Gallons per day of Pure Fresh Drinking Water, and is also equipped with an On-Demand Delivery Pump that can pump up to 26 Gallons per minute to the filling source,

The AP6000-SM-LX is used in many applications such as water stores, bottling plants, food production, beverage production, pharmaceuticals, and various other applications requiring pure Reverse osmosis water.

The AP6000-SM-LX Reverse Osmosis System consist of 14 stages as follows:

1- Spin-Down Manual Flush Screen Pre-Filter to remove suspended solids up to 25 micron.  This pre-filter is clear for visual, cone-shaped that collect the suspended solids at the bottom of the clear housing, once it’s full you can open the valve and all the solids and impurities will drop down to the drain line.

2- Ion Exchange Water Softener with Auto Regeneration Valve to remove Calcium, Magnesium, Lead and Iron converting Hard Water to Soft Water.

3- KDF-GAC-Poly Phosphate Multimedia Pre-Filter with Auto Backwash Valve to remove bacteria, contaminants and impurities for the incoming water source.

4- Activated Coconut Shell Carbon Pre-Filter with Auto Backwash Valve to improve Taste, eliminate Odor and Improve Clarity of Water.

5- 20 Micron Sediment Pre-Filter to remove suspended solids up to 20 micron.

6- 5 Micron Sediment Pre-Filter to remove suspended solids up to 5 micron.

7- Multi-stage Jet Booster R/O Pump to increase the pressure as the next step require higher feed pressure.

8- Low Fouling TFC High Flow Membrane Elements to remove dissolved solids, those TFC membrane elements are designed to consistently, efficiently, and reliably produce pure RO water under 10ppm for consumption as per the Health Department requirement for bottling pure water applications. Then Finally Pure Water is stored in Water Storage Tanks.

9- Smart on-Demand Delivery Pump, this pump will re-pressurize the line from the storage tank all the way to the filling station.

10- 4" x 20" Big Blue Carbon Post-Filter to improve taste odor and clarity of the purified water.

11- Stainless Steel Ultra Violet Sterilizer to disinfect the pure water as it is filling the water bottles.

12- Ozone Circulation Loop to maintain the Water Storage Tanks Sterilized and Bacteria Free at al Times

13- Alkaline post Filter to regulate the pH level to a desired level.

14- The A6000-SM-LX is also equipped with an Automatic Programmable logic controller (PLC) with an LCD Screen to monitor the whole process.  This PLC will give you a peace of mind as it is designed to operate and monitor the whole RO System, it is also equipped with a TDS Water Quality Monitor, a Water Temperature Monitor, and an Hour Monitor to count the hours of operations, making simple to service the reverse osmosis.

• The AP6000-SM-LX is also equipped with Stainless Steel / Liquid Filled Pressure Gauges after every stage to facilitate service and troubleshooting.
• The RO system is also equipped with Permeate and concentrate (Product & Drain) Flow Meters so the operator can monitor the recovery rate of the membrane elements, as well it has a Recycle Control so you can recover a portion of the waste water.
• The AP6000-SM-LX Water Purification System can also be configured to produce purified alkaline water.  This water purification system can be easily modified for higher production levels at a later date and easily adaptable for various uses.
• The AP6000-SM-LX Reverse Osmosis System features a unique design allowing it to be extremely reliable with low maintenance costs. The system is comprised of basic UL Approved electrical components and NSF Approved plumbing components that are readily accessible for easy service and maintenance.
• The AP6000-SM-LX Reverse Osmosis system is built upon order allowing our technicians to customize the system to meet the client’s requirements in the most efficient, affordable, and reliable design. Also the system can be tailored to fit practically any location such as space, door size, etc…
• All our Water Purification Systems are manufactured and fully assembled in the USA with UL/NSF approved components.
• The AP6000-SM-LX Reverse Osmosis Water Purification System is made with locking wheels allowing it to be easily moved and repositioned during moving, maintenance, cleaning, etc.
• The system comes with a one year full warranty from Ampac USA to be free from defect.
• The AP6000-SM-LX reverse osmosis system is user friendly, easy to install, and comes with a complete detailed operation and installation manual to facilitate maintenance, and installation procedures.

Standard Features:

• Spin Down Auto Flush Screen Pre-Filter
• Ion Exchange Water Softener with Auto Regeneration Valve
• KDF-GAC-Poly Phosphate Multimedia Pre-Filter with Auto Backwash Valve
• Activated Coconut Shell Carbon Pre-Filter with Auto Backwash Valve
• 20" Sediment Pre-Filter ( 20 Micron)
• 20" Sediment Pre-Filter (   5 Micron)
• 4" x 40" Low Fouling TFC High Flow Membrane Element
• 4" x 40" Stainless Steel Pressure Vessel
• 4" x 20" Big Blue Carbon Post-Filter
• Stainless Steel Ultra Violet Sterilizer
• Panel Mount Digital TDS Water Quality monitor
• Goulds Multi-stage Jet Booster R/O Pump
• Grundfos Smart on-Demand Delivery Pump
• Auto/Manual PLC (Processor) w/Delayed start-up of R/O pump & Auto-Flush
• Stainless Steel / Liquid Filled Pre-Filter Pressure Gauges
• Permeate (Product) Flow Meter
• Concentrate (Waste) Flow Meter
• Stainless Steel System Pressure Control
• Stainless Steel Recycle Valve Control
• John Guest Quick Disconnect Fittings
• Powder Coated Aluminum Welded Frame with Aluminum Diamond Plate.

*Prices are subject to change without notice.
