Portable Reverse Osmosis 3000 GPD | PCRO-3000

Brand: Ampac USA
Product Code: PCRO-3000
Made in USA
qrcode

Download Attachment(s):

The AMPAC USA Emergency Portable Reverse Osmosis 3000 GPD| PCRO-3000 Unit that has been specifically designed for Disaster Preparedness Applications, where large amounts of pure water is required at the cheapest running costs.
The PCRO-3000 will Produce up to 2 GPM (Gallons per Minute) of Pure water


Standard Features:

  • Production GPD: 3,000 Gallons Per Day
  • Production LPD:  11,350 Liter Per Day
  • 4” x 10” Sediment Pre-Filter 20 Micron
  • 4” x 10” Carbon Block Pre-Filter 5 Micron
  • Rotary Vane High-Pressure Jet Booster Pump with Safeguards
  • 4" x 20" Activated Coconut Shell Post-Filter to improve Taste, Odor, and Clarity
  • Ultra-Violet Disinfection Sterilizer to sterilize pure water output
  • Stainless steel liquid-filled pressure gauge
  • Low pressure cut off switch
  • 4” x 21” FRP Steel Pressure Vessels
  • TFC 4” x 21” Membrane Elements.
  • Stainless Steel System Pressure Control
  • Heavy-Duty FRP Pressure Vessel
  • On/Off Main Power Switch
  • Powder-coated, Heavy Duty Fully Welded Light Cart on Wheels
  • 12 Month Warranty.

System Features:

FramePowder Coated Aluminum Cart
Membranes(3) ea TFC 4" x 21"
Vessels4" x 21" FRP
PumpProcon Rotary Vane with Safeguards (SS option)
Gauges - Glycerin FilledBooster Pump PSI
ValvesSystem Pressure
SwitchesLow-Pressure Cutout, High-Pressure Cutout
Electrical110 or 220 V, 50 or 60 Hz, 1 phase
Motor1 Hp - 1725 rpm
Connections1/2" Quick Tubing Connectors
Capacity per US Gallon2.0 gal per min - 3,000 gals per day
Capacity per Liters7.9 Liters per min - 11,350 Liters per day
Operating Pressure170 - 225 psi
Typical Recovery40% - 75%
Typical Rejection99.2%
Max Feed  TDS - Hardness2500 ppm - 15 grains For Municipal Water Design
Max Feed  TDS - Hardness10,000 ppm - 25 grains For Brackish Water Design
Max Feed Temp113 degrees F
Feed pH Range3 -11
Max Chlorineless than 0.1 ppm
Dimensions37" wide x 21" deep x 35" ht.
